型號 | 主機(jī)型號 | 功率(KW) | 氣量/壓力 | 出口尺寸 | 機(jī)組重量KG | 機(jī)組尺寸(L×W×H)mm |
GLFII110-7 | BHE226L | 110 | 24.5m3/0.7mpa | DN65 | 3360 | 2666×1730×1918 |
GLFII110-8 | 23.5m3/0.8mpa | |||||
GLFII110-10 | 19.7m3/1.0mpa | |||||
GLFII110-13 | 17.6m3/1.3mpa | |||||
GLFII132-7 | BHE226L | 132 | 30m3/0.7mpa | DN80 | 3450 | 2866×1730×1918 |
GLFII132-8 | 28m3/0.8mpa | |||||
GLFII132-10 | 23.5m3/1.0mpa | |||||
GLFII132-13 | 19.8m3/1.3mpa | |||||
GLFII160-7 | BHE300L | 160 | 34.5m3/0.7mpa | DN80 | 3850 | 2866×1730×1918 |
GLFII160-8 | 33.6m3/0.8mpa | |||||
GLFII160-10 | 30m3/1.0mpa | |||||
GLFII160-13 | 23.8m3/1.3mpa |
